Skyla VB1

Veterinary Clinical Chemistry Analyzer is the Best Pet's Health Guardian

The Skyla VB1 Veterinary Clinical Chemistry Analyzer is a compact system designed to perform blood biochemistry tests – fast, reliable and with high accuracy. Applying only a few blood can suffice to perform up to 15 tests on the veterinary patient sample.
It’s easy-to-use and simple operation requires no specialized training and enables you to obtain results in about 15 minutes with the precision and accuracy equivalent to those of a clinical laboratory analyzer.

Smart Experience
Simple 3-step Procedures
The device provides fully automatic procedures to test samples with only three steps :

Step1. Inject 200 μl blood sample
Step2. Press "START" and then insert reagent disc
Step3. Read the results

Device

• User Interface
• 5 inch color LCD touch screen
• Internal Memory
• Store up to 50,000 analysis results
• Printer
• Built in thermal printer or external USB printer
  (PCL 3GUI)
• USB Socket
• USB type A (Host) for external USB Printer, USB
  flash drive (FAT) or external barcode scanner
• Data transmission to PC
• RS232 serial port or RJ45 (LAN)
• Dimensions
• 233 (W) X 285 (D) X 300 (H) mm
• Weight
• 5 kg

Operating Condition

• Temperature / Humidity
• 10 to 32˚C / 5 to 90 %

Sample & Panel

• Test Profiles
• Panels
• Measurement Time
• Panel: up to 15 tests/ 15 min
• Sample Type & Volume
• 200 μl whole blood (PCV<60%), plasma, serum
