Description
Click here to download PDF catalog
i-DR43 is a high performance dynamic flat panel detector, with high image quality, high dynamic range, high frame rate and other excellent quality. It can meet the requirements of a variety of applications, including CBCT, gastro enterography, industrial flaw detection, etc.
Complete synchronous interface is provided to facilitate linkage with other components such as high voltage generator.
Mature SDK integrate with operation software faster.
Technical Parameters
|
Model Name |
i-DR43 |
|
Technology |
a-Si |
|
Scintillator |
CSI/GOS |
|
Pixel Pitch |
140㎛ |
|
Spatial Resolution |
3.6Lp/㎜ |
|
Pixel Matrix |
3072 x 3072 pixels |
|
Image Size |
17" x 17" (43 x 43.0 ㎝) |
|
Grayscale |
16 bits |
|
Image Acquisition Time |
Wired: 1 s |
| Data Interface |
Gigabit Ethernet IEEE 802.11n |
|
X-ray Generator Interface |
DR Trigger Mode / AED Mode |
|
X-ray Voltage Range |
40 - 150kV |
|
Dimensions |
46 ㎝ x 46.0 ㎝ x 1.6 ㎝ |
|
Weight |
3.2kg (Wired) 3.7kg (Wireless) |
|
Battery |
Lithium Ion 4000mAh |
|
Dust and Water Resistant |
IPX3 |
|
Housing Material |
Carbon/Alloy |
|
Operating Environment |
5℃ to 35℃ |
|
Power Consumption |
DC 24 V, 0.5 A |
